Pisco VUH07-64J Vacuum Generator VU

Pisco VUH07-64J Vacuum Generator VU

Size
vacuum port tube outer diameter (V): 6
Air supply port tube outer diameter (P): 4mm
Exhaust port tube outer diameter (EX): 6mm

Vacuum characteristics
high vacuum degree type
Nozzle diameter: 0.7mm
Arrival vacuum level: -92kPa
Suction flow rate: 12.5L/min(ANR)
Consumption flow rate: 23L/min(ANR)

Features
●Change compressed air into vacuum, Can be used for conveying workpieces (things) in combination with vacuum pads.

Specifications
● Fluid used: Air
● Operating pressure range: 0.15 to 0.7 MPa
● Rated supply pressure: 0.5 MPa
●Operating temperature range: 0 to 60 °C (without freezing)

Material
● Resin body: PBT
● Metal body: brass + electroless nickel plating
●Open ring: POM
●Seal rubber: NBR

Mass

21.5g
