Pisco VHE07-601J Vacuum Generator VH

Pisco VHE07-601J Vacuum Generator VH

Size
Vacuum port tube outer diameter (V): 6mm
Air supply port screw size (P): R1/8
Exhaust port tube outer diameter (EX): 8mm

Vacuum characteristics
Low supply pressure high vacuum degree
nozzle diameter: 0.7mm
Reach vacuum degree: -92kPa
Suction flow rate: 10.5 L / min (ANR)
Consumption flow rate: 17 L / min (ANR)

Features
● Compressed air is changed to vacuum and can be used for conveying workpieces (things) by changing compressed air to vacuum and combining it with a vacuum pad.

Specifications
● Fluid used: Air
● Operating pressure range: 0.15 to 0.7 MPa
● Rated supply pressure: 0.35 MPa
● Operating temperature range: 0 to 60 °C (without freezing)

Material
● Resin body: PBT
● Metal body: brass + electroless nickel plating, aluminum
● Open ring: POM
● Seal rubber: NBR

Mass

45g
