Pisco VGE07B-66 Vacuum Generator VG

Pisco VGE07B-66 Vacuum Generator VG

Size
vacuum port tube outer diameter (V): 6
Air supply port tube outer diameter (P): 6mm

Vacuum characteristics
Low supply pressure high vacuum degree
rated supply pressure: 0.35MPa
Nozzle diameter: 0.7mm
Arrival vacuum degree: -90kPa
Suction flow rate: 10.5L/min (ANR)
Consumption flow rate: 17L/min (ANR)

Features
●Unitized pressure sensors, vacuum failure valves, etc. Types can be selected according to the purpose of use.
- Three types of pressure sensors are available. : Switch output + analog output, 2-point switch output, and inexpensive analog output only available.

Specifications
● Fluid used: Air (JIS B8392-1: According to "Grade 1.2.1 to 2.4.3")
● Operating pressure range: 0.25 to 0.7 MPa
●Operating temperature range: 5 to 50 °C (without freezing)
● Operating humidity range: 35 to 85% RH (non-condensing)
● Vibration resistance / Shock resistance: 50m / s ^ 2 or less / 150m / s ^ 2 or less
● Protective structure: IP40 equivalent
● Refueling: unnecessary
-Pressure resistance: 1.05MPa (air supply circuit), 0.2MPa (vacuum circuit) (pressure resistance simply represents [pressure that does not damage the product], unlike the pressure that the product can use normally)

Mass

75g
