Pisco VFL360-12-1M Vacuum Filter

Pisco VFL360-12-1M Vacuum Filter

With or without bracket

With bracket

Size
tube outer diameter (φD): 12 mm

Filtration area
64.4cm²

Features
● Because it is large capacity, flow rate priority. During air suction, dust and dust that are sucked together are removed to protect vacuum generators and vacuum pumps.
- Filtration excess can be selected from 4 types according to the application.
- Connection shape is abundant.
- Lightweight because the body is resin.

Specifications
● Fluid used: Air
● Operating pressure range: -101 to 0 kPa
● Filtration excess: 1 μm (collection efficiency: 95%) (depending on our measurement conditions)
● Operating temperature range: 0 to 60 °C (without freezing)

Material
● Resin body: PBT
● Metal part: stainless steel, iron + nickel plating, aluminum
● Seal rubber: NBR
● Filter cover: PC
- Filter element: PE + PP

Mass

513g
