Pisco VFL360-03-200M Vacuum Filter



With or without bracket

Size
female thread size (Rc): Rc3/8

Filtration area
64.4cm²

Features
● Because it is large capacity, flow rate priority.
- Filtration excess can be selected from 4 types according to the application.
- Connection shape is abundant.
- Lightweight because the body is resin.

Specifications
● Operating fluid: Air
● Operating pressure range: -101 to 0 kPa
● Filtration excess: 200 μm (collection efficiency: 95%) (depending on our measurement conditions)
● Operating temperature range: 0 to 60 °C (without freezing)

Material
● Resin body: PBT
● Metal part: stainless steel, iron + nickel plating, aluminum
● Seal rubber: NBR
● Filter cover: PC
- Filter element: PE + PP

Mass

522g
