Pisco LP-M5-C Minimal Barb

Pisco LP-M5-C Minimal Barb

Size
Screw size (M): M5×0.8

Features
● Barb fitting ideal for space-saving piping. In combination with our vacuum tube (UD), it is also ideal for piping vacuum equipment.
●We implement clean room packaging that is ideal for piping in a clean environment. (After cleaning with clean air using fluorine-based grease, packaging in a clean room (equivalent to ISO Class 6).

Specifications
● Fluid used: Air
● Maximum operating pressure: 1.0MPa
●Vacuum pressure used: -100 kPa
●Operating temperature range: 0 to 50 °C (without freezing)

Material
● Metal body: brass + electroless nickel plating

Mass

1.5g
