Pisco LC-0640-M5-C Minimal Barb

Pisco LC-0640-M5-C Minimal Barb
Manufacturer: Pisco
SKU: PS-LC-0640-M5-C
Manufacturer part number: LC-0640-M5-C

Pisco LC-0640-M5-C Minimal Barb

Size
Tube inner diameter (φD): 4mm
screw size (M): M5×0.8

Features
● Barb fitting ideal for space-saving piping. In combination with our vacuum tube (UD), it is also ideal for piping vacuum equipment.
●We implement clean room packaging that is ideal for piping in a clean environment. (After cleaning with clean air using fluorine-based grease, packaging in a clean room (equivalent to ISO Class 6).

Specifications
● Fluid used: Air
● Maximum operating pressure: 0.5 MPa
●Vacuum pressure used: -100 kPa
●Operating temperature range: 0 to 50 °C (without freezing)


Material
● Metal body: brass + electroless nickel plating

Mass

1.5g
